Name: WAYFARER 0.9m Driveaway Antenna - Single Offset
Brand: Norsat International Inc.
SKU: WDA090KAS
Price: 42625.00 USD
Availability: InStock

WAYFARER 0.9m Driveaway Antenna - Single Offset

WDA090KAS

WAYFARER 0.9m Driveaway Antenna - Single Offset

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

[{"id":51747508650351,"title":"Ka-Band","option1":"Ka-Band","option2":null,"option3":null,"sku":"WDA090KAS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"WAYFARER 0.9m Driveaway Antenna - Single Offset - Ka-Band","public_title":"Ka-Band","options":["Ka-Band"],"price":4262500,"weight":0,"compare_at_price":4262500,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":51747508683119,"title":"Ku-Band","option1":"Ku-Band","option2":null,"option3":null,"sku":"WDA090KUS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"WAYFARER 0.9m Driveaway Antenna - Single Offset - Ku-Band","public_title":"Ku-Band","options":["Ku-Band"],"price":3987500,"weight":0,"compare_at_price":3987500,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

KEY SPECIFICATIONS
antenna aperture	0.9 m
antenna category	Drive Away
band	Ka-Band
number of onboard Los	Single-Band
Product Revision	A

ANTENNA SPECIFICATIONS
antenna type	Single Offset
cross polarization isolation	25 dB
motion range AZ	±220°
motion range EL	0° - 90°
motion range POL	±90°
polarization	Circular
sidelobe	≤-14dB

RF SPECIFICATIONS
port isolation Rx-Tx	≥85dB
port isolation Tx-Rx	≥40dB
power capacity	≤1000 W
Rx frequency	10.95 - 12.75 GHz
rx gain	38.7+20lg(f/12.5)dBi
Rx interface	WR42
Rx VSWR	≤ 1.5 : 1
Tx frequency	13.75 - 14.50 GHz
tx gain	39.5+20lg(f/14.25)dBi
Tx interface	WR28
Tx VSWR	≤ 1.5 : 1

ENVIRONMENTAL SPECIFICATIONS
humidity	95%（20°C）
IP rating	IP65
temperature operational	-40°C to +60°C
temperature storage	-50°C to +70°C
windspeed operational	13m/s
windspeed survival	20m/s

PHYSICAL SPECIFICATIONS
product weight	56 kg

INFORMATION
HS Code	8529109090
Country of Origin	Made in China
Ex Works	Hong Kong
ECCN Number	EAR99
Warranty	1 year
Unit Package Dimensions	-
Unit Package Weight	-
