ACC-100749

60cm Ku-Band Antenna, One Dish Reflector, Feed, OMT

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



ANTENNA SPECIFICATIONS
1st Sidelobe Azimuth Tx < -11.0 dB
1st Sidelobe Elevation Tx < -11.0 dB
Azimuth (H-Plane) Beamwidth

Tx: 2.9 ± 0.3° @ 14.0 GHz
Rx: 3.5 ± 0.3° @ 11.5 GHz
Cross Polarization -30 dB max
EIRP-SD @ 14.2 GHz 36.7 dBW/ 40 KHz
Elevation (E-Plane) Beamwidth

Tx: 2.9 ± 0.3° @ 14.0 GHz
Rx: 3.5 ± 0.3° @ 11.5 GHz
isolation

Tx: 74.2 dB
Rx: 47.5 dB
Patterns

Eutelsat EESS-502
Intelsat IESS-601
Polarization Linear Orthogonal with Skew Control
Reflector Aperture 60cm
Rx frequency 10.70 - 12.75 GHz
rx gain 34.5 dB @ 11.725 GHz
Tx frequency 13.0 - 14.50 GHz
tx gain 36.2 dB @ 13.75 GHz
VSWR Tx: 1.78:1 max. , Rx: 1.60:1 max.
ENVIRONMENTAL SPECIFICATIONS
temperature operational -40 to +60°C
PHYSICAL SPECIFICATIONS
maximum turning torque < 10 in-lbs over full temperature range
