ACC-100438
Band Pass Filter
Regular pricePlease sign in or create an account to view the price and availability.
(Scroll to see specifications and documents)
Send a copy to email:
By entering your email, you agree that it will be seen by the store Norsat and may contact you.
Email is required.
Or download now:
Something went wrong. Please try again.
Open here
| KEY SPECIFICATIONS | |
|---|---|
| input frequency band 1 | 3.40 - 4.20 GHz |
| Product Revision | B |
| RF SPECIFICATIONS | |
|---|---|
| insertion loss | 0.04 dB max |
| rejection | 70 dB typ |
| rejection range | 5.825 - 6.725 GHz |
| VSWR | 1.25 : 1 max. |
| INTERFACE SPECIFICATIONS | |
|---|---|
| IF output connector | CPR 229F |
| RF input connector | CPR 229G |
Please contact us to request any additional documents you may need.
Please contact us to request any additional documents you may need.
Please contact us to request any additional documents you may need.
| INFORMATION | |
|---|---|
| HS Code | 8517690000 |
| Country of Origin | Made in United States of America |
| Ex Works | Richmond, BC, Canada |
| ECCN Number | EAR99 |
| Warranty | - |
| Unit Package Dimensions | - |
| Unit Package Weight | - |
| Total Aluminium Content | - |
| Aluminum Country of Smelt and Cast | - |
| Total Aluminium Value | - |
