BT-100003

Bias Tee BT-100003

$650.00

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 28 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
band L-Band
pass band 950 - 2150 MHz
Product Revision B
RF SPECIFICATIONS
10MHz pass band 10 - 100 MHz
input VSWR 2.0 : 1 max.
insertion loss max 1 dB
output VSWR 2.0 : 1 max.
INTERFACE SPECIFICATIONS
10MHz injection SMA (Female) - 50 Ohm
DC connector SMA (Female) - 50 Ohm
output connector SMA (Female) - 50 Ohm
RF input connector SMA (Female) - 50 Ohm
ENVIRONMENTAL SPECIFICATIONS
temperature operational -30 to +50˚C
temperature storage -40 to +70˚C
PHYSICAL SPECIFICATIONS
product height 25 mm
product length 105 mm
product weight 0.17 kg
product width 55 mm
