100W Power Supply
100W Power Supply
100W Power Supply
100W Power Supply

ACC-101067

100W Power Supply

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
output power rated 100W
Product Revision A
ELECTRICAL SPECIFICATIONS
ac module output power 70W to 100W
dc blade output power 70W to 100W
dc input current 3.3 A max.
operating ac frequency 47 - 63 Hz
operating voltage ac 85 - 264 VAC
operating voltage dc 38 - 72 VDC
peak inrush current 50 A max.
M and C SPECIFICATIONS
led indicators

GREEN: OK, Sharing Current Load with a Redundant Power Supply
GREEN BLINKING: OK, NOT Sharing Current Load with a Redundant Power Supply, Single Power Supply Operation
RED FAULT: No Input Power or Internal Failure
ENVIRONMENTAL SPECIFICATIONS
altitude 10,000 ASL
relative humidity 20% to 90%
temperature operational 0°C to 50°C
temperature storage -40°C to 85°C
PHYSICAL SPECIFICATIONS
product height 38.8 mm
product length 220 mm
product weight 0.410 kg
product width 68 mm
