LNB-100155

Ku-Band LNB

$1,864.00

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
band Ku-Band
input frequency band 1 10.70 - 12.75 GHz
LO frequency 1 10.6 GHz
noise figure max 1.0 dB
noise figure typ 0.9 dB
output frequency band 100 - 2150 MHz
Product Revision C
RF SPECIFICATIONS
conversion gain max 65 dB
conversion gain min 55 dB
conversion gain typ 60 dB
Gain Flatness ( over full band) 8 dB p-p max.
Gain Ripple at Per 27MHz 1dB p-p max.
Image rejection 25dBc min.
input VSWR 2.5 : 1 max.
output P1dB + 5 dBm min.
output VSWR 2.5 : 1 max.
ELECTRICAL SPECIFICATIONS
power requirements +12 to +24V DC
Required Current 350mA max.
INTERFACE SPECIFICATIONS
IF connector N-Connector
RF input connector WR-75 waveguide grooved
M and C SPECIFICATIONS
led indicators None
ENVIRONMENTAL SPECIFICATIONS
temperature operational -40 to +60°C
PHYSICAL SPECIFICATIONS
product height 41.6 cm
product length 111.5 cm
product weight 0.38 kg
product width 60 cm
Waterproof IP67
