1000 Ku-Band Single Band PLL LNB
1000 Ku-Band Single Band PLL LNB
1000 Ku-Band Single Band PLL LNB

LNB-100148

1000 Ku-Band Single Band PLL LNB

1000H-2 Series

$374.00

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
band Ku-Band
input frequency band 1 11.40-12.2 GHz
LO frequency 1 10.5 GHz
LO type PLL
noise figure max 0.9 dB
noise figure typ 0.8 dB
number of onboard LOs Single-Band
output frequency band 1 900-1700 MHz
Product Revision A
RF SPECIFICATIONS
conversion gain max 65 dB
conversion gain min 55 dB
conversion gain typ 60 dB
input VSWR 2.5 : 1 max.
output P1dB + 5 dBm min.
output VSWR 2.5 : 1 max.
ELECTRICAL SPECIFICATIONS
current consumption 350 mA
power requirements +12 to +24 V
INTERFACE SPECIFICATIONS
RF input connector WR-75 waveguide grooved
M and C SPECIFICATIONS
led indicators None
ENVIRONMENTAL SPECIFICATIONS
humidity 0 - 95%
temperature operational -40 to +60°C
temperature storage -40 to +80°C
PHYSICAL SPECIFICATIONS
product height 41.6 cm
product length 111.5 cm
product weight 0.4 kg
product width 60 cm
