LUMID040-05A

LUMENIX Handheld SLAM LiDAR Scanning Systems 40m

LUMENIX Industrial

Regular price

Please sign in or create an account to view the price and availability.


(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
accuracy absolute ≤5 cm
accuracy relative ≤1 cm
battery capacity 11600 mAh
battery duration 2h
camera effective pixel 2*20 MP
camera scanning mode SHARE
laser data Single echo, 200,000 Points/Sec
laser horizontal FOV 360°
laser measuring range 40m
laser range accuracy ±1.5cm
laser scanning mode Hybrid Solid-State Laser Radar
laser vertical FOV -7° - 52°
mapping mode SLAM; RTK-SLAM; PPK-SLAM
operating time 2 - 2.5h
POS GNSS signal type GPS L1/L2; GLO L1/L2; GAL E1/E5b; BDS B1/B3/B2a (Supports BeiDou-only Mode)
POS heading accuracy 0.040°
POS pitch accuracy 0.015°
POS positioning accuracy horizontal ±0.02m
POS positioning accuracy vertical ±0.03m
POS roll accuracy 0.015°
POS update rate 200 Hz
response time real-time
Product Revision A
ELECTRICAL SPECIFICATIONS
operating voltage 12 - 20V
power consumption <25 W
INTERFACE SPECIFICATIONS
point cloud density The density of points can be adjusted by changing the walking speed.
processing storage Point Cloud Creater
real-time point cloud Support
software point cloud automata (Optional) PCA software - point cloud classification and post processing software
software point cloud creater Perpetual license - Self-developed PointCloud Creater software
storage 128GB MicroSD Card
supported platform Handheld/Backpack/Other DIY options available
ENVIRONMENTAL SPECIFICATIONS
temperature operational -20°C to 55°C
temperature storage -40°C to 70°C
PHYSICAL SPECIFICATIONS
material Aluminum Alloy Body
product height 324 mm
product length 165 mm
product weight 1 kg
product width 120 mm
