LUMID300-10D

LUMENIX Lightweight, high precision LiDAR system

LUMENIX Industrial

Regular price

Please sign in or create an account to view the price and availability.


(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
accuracy absolute 10cm@150m
accuracy relative ±1 cm
camera effective pixel 26MP
camera scanning mode SHARE
laser data Double echo, 1,280,000 Points/Sec
laser horizontal FOV 360°
laser measuring range 300m
laser range accuracy ±1cm
laser scanning mode 32-Channel
mapping mode RTK/PPK
POS GNSS signal type GPS L1/L2; GLO L1/L2; GAL E1/E5b; BDS B1/B3/B2a (Supports BeiDou-only Mode)
POS heading accuracy 0.017°
POS pitch accuracy 0.005°
POS positioning accuracy horizontal ≤0.05m
POS roll accuracy 0.005°
POS update rate 200 Hz
response time real-time
Product Revision A
ELECTRICAL SPECIFICATIONS
operating voltage 12 - 24V
power consumption 20W
INTERFACE SPECIFICATIONS
point cloud density 53pts/㎡@150m@10m/s
processing storage Point Cloud Creater
software mission planning software (Optional) Customized Route Planning Software — WayPoint Master
software point cloud automata (Optional) PCA software - point cloud classification and post processing software
software point cloud creater Perpetual license - Self-developed PointCloud Creater software
storage 64GB, Max support 256GB TF card
supported platform Multi-Rotor Drones, vehicals/Other DIY options available
ENVIRONMENTAL SPECIFICATIONS
temperature operational -20°C to 55°C
temperature storage -40°C to 70°C
PHYSICAL SPECIFICATIONS
material Aluminum Alloy Body
product height 120 mm
product length 144 mm
product weight 1.1 kg
product width 109 mm
