| KEY SPECIFICATIONS | |
|---|---|
| allan deviation 1s | <2E-10 |
| frequency stability | <3E-10/month |
| holdover | ±25 ns sync; <1μs/24h holdover |
| RF SPECIFICATIONS | |
|---|---|
| output level | CMOS 3.3V |
| phase noise 10khz | <-143 dBc/Hz |
| phase noise 1hz | <-50 dBc/Hz |
| INTERFACE SPECIFICATIONS | |
|---|---|
| output signal format | CMOS, 3.3V @ 1MΩ |
| serial interface | USB or RS-232 interface |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| operating temperature | -40°C to +80°C |
| storage temperature | -55°C to +85°C |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| product height | 30 mm |
| product length | 100 mm |
| product weight | 0.2 kg |
| product width | 80 mm |
