| KEY SPECIFICATIONS | |
|---|---|
| camera effective pixel | 7680 × 3840 (stitched in camera) |
| camera FOV horizontal | 360° |
| camera FOV vertical | 360° |
| data rates | 1-60MB H264/H265 |
| in-camera stitching | Support 8K in-camera_stitching |
| lens type | Four 190-degree F2.2 2.3mm fisheye lenses |
| sensor size | 1/1.8 inch (×4) |
| streaming protocol support | RTMP/RTSP//GB/T 28181-2016 |
| video record | MP4 |
| Product Revision | A |
| ELECTRICAL SPECIFICATIONS | |
|---|---|
| operating voltage | 12.6V |
| power consumption | 18W |
| INTERFACE SPECIFICATIONS | |
|---|---|
| communication interface | 1000M Ethernet |
| storage | 32G emmc |
| supporting application | Supports In-Camera Stitching, Live Streaming and Surveillance Applications |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| IP rating | IP68 |
| temperature operational | -30°C to +60°C |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| product height | 123 mm |
| product length | 78 mm |
| product weight | 1.2 kg |
| product width | 78 mm |
