| KEY SPECIFICATIONS | |
|---|---|
| battery capacity | 6800mAh |
| camera effective pixel | 7680 × 3840 (stitched in camera) / 4 channels 3840*2304 |
| camera FOV horizontal | 360° |
| camera FOV vertical | 360° |
| data rates | 1-100MB H264/H265 |
| in-camera stitching | Support 8K in-camera_stitching |
| lens type | Four 200-degree F2.2 2.0mm fisheye lenses |
| sensor size | 1/2.3 inch (×4) |
| streaming protocol support | RTMP/RTSP/RTMP Server/GB/T 28181-2016/SRT |
| video record | MP4 |
| Product Revision | A |
| ELECTRICAL SPECIFICATIONS | |
|---|---|
| operating voltage | 12.6V |
| power consumption | 18W |
| INTERFACE SPECIFICATIONS | |
|---|---|
| communication interface | 1000M Ethernet |
| storage | Internal UFS 512GB |
| supporting application | Supports In-Camera Stitching, Photography, Video Recording and Live Streaming |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| IP rating | IP66 |
| temperature operational | -10°C to +40°C |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| product height | 150 mm |
| product length | 55 mm |
| product weight | 0.62 kg |
| product width | 55 mm |
