OPT169BR

OPTIVIA Light Gimbal Camera

Electro-Optical PODs

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
optional upgrade devices LRFB3000CD or LRFB5000DD
recording time ≥60 min ≥ Small drone flight time
stabilization accuracy horizontal jitter angle ±0.03°
stabilization accuracy pitch jitter angle ±0.02°
stabilization accuracy roll jitter angle ±0.02°
standard preinstalled components 1080P Zoom Camera; Laser Rangefinder; Thermal Infrared Camera
Product Revision A
RF SPECIFICATIONS
IR detection range ≥3.8km
IR detector type (VOx) Uncooled infrared microbolometer camera
IR focal length 35mm
IR fov 35mm lens FOV: 12.52° × 10.03°
IR identification range ≥1.6km
IR resolution 640×512
IR temperature color panel status Black Hot, White Hot, Pseudo-color (≥8 types)
IR temperature measurement range -20°C to 150°C, expandable to 100°C to 550°C
IR thermal sensitivity netd 50mk@F1.0
IR wavelength range 8 - 14μm
laser rangefinder accuracy ±1
laser rangefinder operating wavelength 1535nm ± 10nm (Class I safety laser)
laser rangefinder ranging range 50 - 5000m
visible light detection detection tracking target size 4m × 6m
visible light detection maximum relative humidity 70%
visible light detection minimum visibility ≥23 km
visible light detection range ≥6km
visible light fov diagonal WIDE 67.8° ± 5% TELE 2.77° ± 5%
visible light fov horizontal WIDE 59.8° ± 5% TELE 2.34° ± 5%
visible light fov vertical WIDE 40.5° ± 5% TELE 1.48° ± 5%
visible light identification range ≥4.5km
visible light minimum identifiable target size 32×32 pixels
visible light resolution 1920×1080
ELECTRICAL SPECIFICATIONS
power consumption Dynamic 10W
power supply DC 12V - 26.2V
INTERFACE SPECIFICATIONS
control method SBUS, PWM signal (requires decoding board), UART command (standard), Network lP(standard)
external interface communication interface TTL
external interface video interface RTSP 1080P 30FPS picture-in-picture output
ENVIRONMENTAL SPECIFICATIONS
temperature operational -10°C to +55°C (20% - 80% RH)
temperature storage -20°C to +60°C (20% to 95% RH)
PHYSICAL SPECIFICATIONS
product height 195 mm
product length 169 mm
product weight 1.58 kg
product width 165 mm
roll angle elevation -45° to +45°
rotation range azimuth 360° continuous rotation
rotation range elevation -30° to +120° (down is positive)
volume 165 x 169 x 195 mm
