OPTIVIA Micro Pod
OPTIVIA Micro Pod
OPTIVIA Micro Pod

OPT040CX

OPTIVIA Micro Pod

Electro-Optical PODs

Regular price

Please sign in or create an account to view the price and availability.


(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
stabilization accuracy 0.2mrad (1°/2Hz) (1σ)
standard preinstalled components Visible Light Imaging Wide Field of View (WFOV); Visible Light Imaging Narrow Field of View (NFOV)
Product Revision A
RF SPECIFICATIONS
visible light fov 98.5° x 66.3° (WFOV, FL2.4 mm); 30° x 17.1° (NFOV, FL10.36 mm)
visible light resolution 1920×1080@30fps
ELECTRICAL SPECIFICATIONS
power consumption Avg 5W; Peak 8W
power supply DC 12 - 16V
INTERFACE SPECIFICATIONS
external interface communication interface TTL
external interface video interface RTSP
ENVIRONMENTAL SPECIFICATIONS
temperature operational -20°C to +60°C
temperature storage -40°C to +60 °C
PHYSICAL SPECIFICATIONS
product height 82 mm
product length 40 mm
product weight 0.08 kg
product width 40 mm
rotation range azimuth -110° to +110°
rotation range elevation -90° to +30°
volume Φ: 40 × H: 82 mm
