ULC-1-50-875126
Universal LNB Controller
Regular pricePlease sign in or create an account to view the price and availability.
(Scroll to see specifications and documents)
Send a copy to email:
By entering your email, you agree that it will be seen by the store Norsat and may contact you.
Or download now:
Open here
| KEY SPECIFICATIONS | |
|---|---|
| 10 MHz Ref. Phase Noise | -120 dBc/Hz@ 10 Hz -135 dBc/Hz@ 100 Hz -150 dBc/Hz@ 1 kHz -155 dBc/Hz@ 10 kHz |
| tone amplitude | 0.55 ~ 0.90 Vpp |
| tone frequency | 20 ~ 24 kHz |
| warm up time | 10 minutes |
| RF SPECIFICATIONS | |
|---|---|
| 10 mhz ref. output power | 0±2 dBm |
| ELECTRICAL SPECIFICATIONS | |
|---|---|
| input voltage range | 23 ~ 25 VDC Power Supply Included |
| LLC line length compensation | +1 VDC (Switch) |
| required current | (warm up) 1100 mA max. (running) 900 mA max. |
| temperature operating | - 40 to + 60°C |
| temperature storage | - 40 to + 80°C |
| INTERFACE SPECIFICATIONS | |
|---|---|
| input interface (from modem) | N-Female Connector |
| input interface (to the LNB) | N-Female Connector |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| product weight | 850 g |
