KEY SPECIFICATIONS |
antenna category |
On the Move |
band |
Ku-Band |
of onboard los |
Single-Band |
Product Revision |
A |
ANTENNA SPECIFICATIONS |
antenna type |
Flat Panel |
cross polarization isolation |
≥ 30dB(axial)(0°&90°)
≥ 25dB(axial)(45°) |
equivalent aperture |
0.8m |
motion range AZ |
360° unlimited |
motion range EL |
5° - 90° |
motion range POL |
360° Unlimited |
polarization |
Linear |
sidelobe |
AZ ≤ -14 dB |
RF SPECIFICATIONS |
port isolation Rx-Tx |
85 dB |
port isolation Tx-Rx |
40 dB |
power capacity |
100 W |
Rx frequency |
10.95 - 12.75 GHz |
rx gain |
≥ 37.0dBi+20lg(f/12.5GHz)dBi |
Rx interface |
WR75 |
Rx VSWR |
≤ 1.8:1 |
Tx frequency |
13.75 - 14.50 GHz |
tx gain |
≥ 38.0dBi+20lg(f/14.25GHz)dBi |
Tx interface |
WR75 |
Tx VSWR |
≤ 1.8:1 |
ENVIRONMENTAL SPECIFICATIONS |
humidity |
95% (20℃) |
IP rating |
IP65 |
temperature operational |
-25℃ - +55℃(cabin equipment); -40℃ - +65℃(Extravehicular equipment) |
temperature storage |
-40℃ - +65℃ |
windspeed operational |
≤ 21m/s |
windspeed survival |
≤ 35m/s |
PHYSICAL SPECIFICATIONS |
product weight |
≤ 110 Kg (excluding BUC, LNB, packaging and accessories) |
INFORMATION |
HS Code |
8517710000 |
Country of Origin |
Made in China |
Ex Works |
China |
ECCN Number |
EAR99 |
Unit Package Dimensions |
- |
Unit Package Weight |
- |
