WFM120KUF

WAYFARER 1.2m Ku-Band Manual Flyaway Antenna - Feed Forward

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!



KEY SPECIFICATIONS
antenna aperture 1.2m
antenna category Manual Flyaway
band Ku-Band
number of onboard LOs Single-Band
Product Revision A
ANTENNA SPECIFICATIONS
antenna type Feed Forward
azimuth angle ±180°
cross polarization isolation ≥30 dB
elevation angle 0° - 90°
polarization Linear
polarization range ±90°
sidelobe ≤ -14 dB
RF SPECIFICATIONS
port isolation Rx-Tx ≥ 85 dB
port isolation Tx-Rx ≥ 40 dB
power capacity ≤500 W
Rx frequency 10.95 - 12.75 GHz
rx gain 41.2+20lg(f/12.25)
Rx interface WR75
Rx VSWR ≤ 1.35 : 1
Tx frequency 13.75 - 14.50 GHz
tx gain 42.5+20lg(f/14.25)
Tx interface WR75
Tx VSWR ≤ 1.35 : 1
ELECTRICAL SPECIFICATIONS
power supply 220 VAC ± 10 50Hz ± 2Hz; ≤350W (not include BUC)
ENVIRONMENTAL SPECIFICATIONS
humidity 95%（20°C）
IP rating IP65
temperature operational -40°C to +60°C
temperature storage -50°C to +70°C
windspeed operational 13m/s
windspeed survival 20m/s
PHYSICAL SPECIFICATIONS
color White
number of cases 1
packed by wood crate and aluminium shipping case
product height 1500 mm
product length 1650 mm
product weight 40 kg
product width 1650 mm
