| KEY SPECIFICATIONS | |
|---|---|
| antenna aperture | 3.7m |
| antenna category | Auto Flyaway |
| band | Ku-Band & Ka-Band & X-Band & C-Band |
| number of onboard LOs | Multi-Band |
| Product Revision | A |
| ANTENNA SPECIFICATIONS | |
|---|---|
| antenna type | Feed Forward |
| azimuth angle | EL>36° AZ: ±180°;EL≤36° AZ: ±60° |
| azimuth velocity | 0.1°/s~3°/s |
| blockage recovery time | ≤1min |
| elevation angle | 0° - 90° |
| elevation veolcity | 0.1°/s~0.05°/s |
| initial auto acquisition time | ≤3min |
| polarization | Linear&Circular |
| polarization velocity | 0.1°/s~3°/s |
| sidelobe | ≤-14dB |
| RF SPECIFICATIONS | |
|---|---|
| port isolation Rx-Tx | ≥85dB |
| port isolation Tx-Rx | ≥40dB |
| power capacity | ≤500W |
| ELECTRICAL SPECIFICATIONS | |
|---|---|
| power supply | 220VAC±10,50Hz±2Hz; ≤600W(No power amplifier) |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| humidity | 95%(20°C) |
| IP rating | IP65 |
| temperature operational | -40°C to +60°C |
| temperature storage | -55℃ to +70℃ |
| windspeed operational | 13m/s |
| windspeed survival | 20m/s |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| color | White |
| default cable (included) | Power supply, network cable, RF Cable |
| default cable length | 10 m |
| number of cases | 6 |
| packed by | wood crate and aluminium shipping case |
| product height | 4500 mm |
| product length | 5500 mm |
| product weight | 655 kg |
| product width | 4200 mm |
