DJI PRODUCT

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



In the box:
DJI Matrice 4T x1
DJI Matrice 4 Series Battery x1
DJI RC Plus 2 Enterprise x1
DJI 100W USB-C Power Adapter x1
DJI Matrice Series Charging Hub(100W)x 1
microSD Card x1
DJI Matrice 4E Gimbal Protectorx 1
DJI Cellular Dongle 2 Pry Barx 1
DJI Matrice 4 Series Propellers (Pair) x3
100W Power Adaptor AC Cable x1
USB-C to USB-C Data Cable x1
USB-A to USB-C Data Cable x1
DJI Matrice 4 Series Storage Case x1
DJI Matrice 4 Series Storage Case Shoulder Strap x1

AIRCRAFT

GENERAL SPECS
Product Revision A
beacon Built into the aircraft
GNSS GPS + Galileo + BeiDou + GLONASS
hover accuracy ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
internal storage N/A
max altitude 6000m (without payload); 4000 m (with payload)
max ascent speed 10 m/s (no accessories); 6 m/s (with accessories)
max descent speed 8 m/s (no accessories); 6 m/s (with accessories)
max flight distance 35 km (standard propellers); 32 km (low-noise propellers)
max flight time no wind 49 min (standard propellers); 46 min (low-noise propellers)
max horizontal speed 21 m/s flying forward, 18 m/s flying backward, 19 m/s flying sideways
max hover time (no wind) 42 min (standard propellers); 39 min (low-noise propellers)
max payload 200 g
max pitch angle 35°
max takeoff weight 1420 g (Standard Propellers); 1430 g (Low-noise Propellers)
max wind speed resistance 12 m/s
operating temperature -10℃ to 40℃ (14°F to 104°F)
ports E-Port interface x 1: Supports official accessories and third-party PSDK devices (hot-swapping is not supported); E-Port Lite interface x 1: supports USB connection to DJI tuning software and some third-party PSDK devices.
propeller model 1157F (standard propellers); 1154F (low-noise propeller)
rec. microsd cards Lexar 1066x 64GB U3 A2 V30 microSDXC; Lexar 1066x 128GB U3 A2 V30 microSDXC; Lexar 1066x 256GB U3 A2 V30 microSDXC; Lexar 1066x 512GB U3 A2 V30 microSDXC; Kingston Canvas GO! Plus 64GB U3 A2 V30 microSDXC; Kingston Canvas GO! Plus 128GB U3 A2 V30 microSDXC; Kingston Canvas GO! Plus 256GB U3 A2 V30 microSDXC; Kingston Canvas GO! Plus 512GB U3 A2 V30 microSDXC
remote controller DJI RC Plus 2 Enterprise
RTK/GNSS accuracy 1 cm + 1 ppm (horizontal); 1.5 cm + 1 ppm (vertical)
supported sd cards U3/Class10/V30 or above is required, or use a memory card from the recommended list.
takeoff weight propellers 1219 g (Standard); 1229 g (Low-noise Propellers)
PHYSICAL SPECS
diagonal wheelbase 438.8 mm
height folded 138.4 mm
height unfolded 149.5 mm
length folded 260.6 mm
length unfolded 307 mm
propeller size 10.8 in
width folded 113.7 mm
width unfolded 387.5 mm

CAMERAS

GENERAL SPECS
ISO range normal mode ISO 100 - ISO 25600
lens aperture f/1.7
lens equivalent FL 24 mm
lens focus 1 m to ∞
lens FOV 82°
minimum photo interval 0.7 s
photo format JPEG
shutter speed 2-1/8000 s
supported file system exFAT
video coding format H.264/H.265
video coding strategy CBR, VBR
video format MP4 (MPEG-4 AVC/H.264)
video max bitrate H264 60Mbps
video max bitrate H265 40Mbps
video resolution 4K 3840 x 2160@30fps
video resolution FHD 1920 x 1080@30fps
WIDE CAMERA SPECS
image sensor 1/1.3-inch CMOS, Effective Pixels: 48 MP
ISO max image size 8064 x 6048
ISO range ISO 100 - ISO 409600 (Night Scene Mode)
photo modes interval 12 MP/48 MP
photo modes JPEG 0.7/1/2/3/5/7/10/15/20/30/60 s
photo modes panorama 12 MP (raw image); 100 MP (stitched image)
photo modes single 12 MP/48 MP
photo modes smart 12MP
TELE CAMERA SPECS
digital zoom 16x (112x hybrid zoom)
image sensor 1/1.5-inch CMOS, Effective Pixels: 48 MP
ISO range ISO 100 - ISO 819200 (Night Scene Mode)
lens aperture f/2.8
lens equivalent FL 168 mm
lens focus 3 m to ∞
lens FOV 15°
max photo size 8192 x 6144
photo modes interval 12 MP/48 MP
photo modes JPEG 0.7/1/2/3/5/7/10/15/20/30/60 s
photo modes single 12 MP and 48 MP
photo modes smart 12MP
MEDIUM TELE CAMERA SPECS
image sensor 1/1.3-inch CMOS, Effective Pixels: 48 MP
ISO range ISO 100 - ISO 409600 (Night Scene Mode)
lens aperture f/2.8
lens equivalent FL 70 mm
lens focus 3 m to ∞
lens FOV 35°
max photo size 8064 x 6048
photo modes interval 12 MP/48 MP
photo modes JPEG 0.7/1/2/3/5/7/10/15/20/30/60 s
photo modes single 12 MP and 48 MP
photo modes smart 12MP
THERMAL CAMERA SPECS
digital zoom 28x
frame rate 30 Hz
imager uncooled vanadium oxide (VOx)
infrared wavelength 8um to 14um
IR photo resolution 1280 x 1024 (Super Resolution on), 640 x 512 (Super Resolution off)
lens aperture f/1.0
lens DFOV 45°±0.3°
lens equivalent FL 53 mm
lens focus 5 m to ∞
measurement method Spot Meter, Area Measurement
palette White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2
photo format JPEG (8bit)、 R-JPEG (16bit)
photo modes interval 1280 x 1024/640 x 512
photo modes JPEG 0.7/1/2/3/5/7/10/15/20/30/60 s
photo modes single 1280 x 1024/640 x 512
pixel pitch 12 μm
resolution 640 x 512
sensitivity ≤50mk@F1.0
temperature accuracy ±2℃ or ±2%, whichever is greater
temperature range -20℃ to 150℃ (-4°F to 302°F)
video bitrate 6.5Mbps (H.264 640 x 512@30fps); 5Mbps (H.265 640 x 512@30fps); 12Mbps (H.264 1280 x 1024@30fps); 8Mbps (H.265 1280 x 1024@30fps)
video format MP4
video resolution 1280 x 1024@30fps (Super Resolution enabled, Night Mode not activated); Other conditions: 640 × 512@30fps

GIMBAL

GIMBAL SPECS
angular vibration range ±0.007°
controllable rotation range -90° to 35° (tilt); Not controllable (pan)
ingress protection rating No Standard Protection Level
max control speed tilt 100°/s
mechanical limits range pan -65° to 65°
mechanical limits range roll -52° to 52°
mechanical limits range tilt -140° to 113°
soft limits range pan -60° to 60°
soft limits range roll -47° to 47°
soft limits range tilt -90° to 35°
stabilization 3-axis (tilt, roll, pan)
temperature oprational -10°C to 40°C (14°F to 104°F)
yaw axis Manual operation is uncontrollable The MSDK interface program is controllable.
GIMBAL MOUNT SPECS

ADDITIONAL SPECS

LASER SPECS
rangefinding 1-3m accuracy System Error <0.3 m, Random Error <0.1 meters @1σ
rangefinding <1m,>3m accuracy ±(0.2+0.0015D) (D represents the measurement distance in meters)
rangefinding blind zone 1 m
rangefinding incidence range Normal: 1800 m (1 Hz) @20% reflectivity target ; 1:5 Oblique Distance: 600 m (1 Hz)
TRANSMISSION SPECS
antenna 8 antennas, 2T4R
latency 130 ms (depending on environmental conditions and mobile device)
live view quality Remote Controller: 1080p/30fps
max distance medium intf Suburban Areas (approx. 5-15 km)
max distance no interference (Unobstructed, free of interference); 25 km (FCC); 12 km (CE); 12 km (SRRC); 12 km (MIC)
max distance strong intf City Centers (approx. 1.5-5 km)
max distance weak intf Suburbs/Seasides (approx. 15-25 km)
max download speed 20 MB/s
operating frequency 2.400-2.4835 GHz; 2.400-2.4835 GHz; 5.725-5.850 GHz; 5.150-5.250 GHz (CE)
others Cellular Dongle Compartment
system O4 Enterprise
transmitter power EIRP 2.4 GHz: ≤33 dBm (FCC), ≤20 dBm (CE/SRRC/MIC); 5.8 GHz: <33 dBm (FCC), <30 dB (SRRC), <14 dBm (CE); 5.15-5.25: < 23 dBm (FCC/CE)

POWER ADAPTER

POWER ADAPTER SPECS
input 100-240 V (AC), 50-60 Hz, 2.5 A
output total Max. 100 W (total)
rated power 100 W

REMOTE CONTROLLER

REMOTE SPECS
accessories Strap/waist support
antenna 2T4R, 2.4GHz/5.8GHz multi-beam high-gain antenna; sub2G Module: 2T2R
audio Array MIC
bluetooth EIRP < 10 dBm
bluetooth operating frequency 2.400-2.4835 GHz
bluetooth protocol Bluetooth 5.2
charging method Supports PD fast charging, with a maximum 20V/3.25A USB Type-C charger
charging temperature 5° to 40° C (41° to 104° F)
charging time 2 hours for internal battery; 2 hours for internal plus external batteries.
enhanced transmission Supports DJI Cellular Dongle 2
external interfaces HDMI 1.4, SD 3.0, USB-C with OTG support, max 65W PD charging, USB-A with USB 2.0 support
GNSS system GPS + Galileo + BeiDou
height 94.5 mm
indicators Status LED, battery level LED, connection status LED, tricolor light, brightness adjustable according to ambient light
length 268 mm
max transmission distance No interference: 40 km (FCC); 20 km (CE/SRRC/MIC)
model TKPL 2
output port HDMI 1.4
screen 7.02-inch 10-Point Multi-touchscreen; resolution: 1920×1200; max brightness: 1400 nits
screen frame rate 60fps
speaker Supports buzzer
storage capacity RAM 8G + ROM 128G UFS + expandable storage via microSD card
storage temperature 1-3months -30° to 35° C (-22° to 113° F)
storage temperature 1month -30° to 45° C (-22° to 140° F)
storage temperature 3-12months -30° to 30° C (-22° to 86° F)
system version Android 11
temperature operational -20° to 50° C (-4° to 122° F)
transmitter power (EIRP) 902-928 MHz: < 30 dBm (FCC), < 16 dBm (MIC); 2.400-2.4835 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC); 5.150-5.250 GHz: < 23 dBm (FCC/CE); 5.725-5.850 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC)
type DJI RC Plus 2 Enterprise
video transmission system DJI O4 Enterprise
weight 1.15 kg (without external battery)
width 163 mm
WIFI operating frequency 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
WIFI protocol Wi-Fi Direct, Wireless Display, IEEE 802.11 a/b/n/ac/ax; Supports 2 x 2 MIMO Wi-Fi, dual-band simultaneous (DBS) support for dual MAC, with data rates up to 1774.5 Mbps (2 x 2 + 2 x 2 11ax dual-band simultaneous)
WIFI transmitter power 2.4ghz < 26 dBm, < 20 dBm (CE/SRRC/MIC)
WIFI transmitter power 5.1ghz < 23 dBm (FCC/CE/SRRC/MIC)
WIFI transmitter power 5.8ghz < 23 dBm (FCC/SRRC), < 14 dBm (CE)
BATTERY SPECS
battery life 3.8 hours (built-in); 3.2 hours (external battery)
built-in battery 2S2P High Energy Density 18650 Lithium-ion Battery (6500 mAh @ 7.2 V) 46.8 Wh
external battery Optional, WB37 (4920 mAh @ 7.6 V) 37 Wh

CHARGING HUB

HUB SPECS
battery support DJI Matrice 4E/T Series Intelligent Flight Battery
input USB-C 5-20 V, max 5 A
output Interface: 11.2 V to 17 V
rated power 100 W
recharging type 4 batteries charging in sequence; Support Standard Mode (100% SOC) and Standby Mode (90% SOC)
temperature 5° to 40° C (41°F to 104°F)

SPOTLIGHT

SPOTLIGHT SPECS
controllable range tilt -90° to 35° (tilt)
dimensions 95 x 164 x 30 mm (with bracket); 79 x 164 x 28 mm (without bracket)
gimbal alignment accuracy ±0.1°
gimbal structural range -140° to 50° (tilt)
illuminance 4.3±0.2 lux @ 100 meters, 17±0.2 lux @ 50 meters
illumination angle 23° (10% relative illumination)
illumination area 1,300 square meters @ 100 meters (10% relative illumination, Normal Mode); 2,200 square meters @ 100 meters (10% central illuminance, Wide fov Mode)
max control speed tilt 120°/s
max power 32 W
mounting Quick-release hand-tightened screws
operating mode Supports always-on and strobe modes.
temperature operational -20°C to 50°C (-4°F to 122°F)
type AL1 Spotlight
weight 99 g (with bracket); Approx. 91 g (without_bracket)

SPEAKER

SPEAKER SPECS
broadcast mode Real-time broadcasting (supports echo suppression*), recorded broadcasting, media import (supports simultaneous transmission and playback), text-to-speech
dimensions 73 x 70 x 52 mm (with bracket); 73 x 70 x 47 mm (without bracket)
effective broadcast distance 300 m
max power 15 W
max volume At 1 meter, it can reach 114 decibels (114dB@1m).
mounting Quick-release hand-tightened screws
temperature operational -20°C to 50°C (-4°F to 122°F)
type AS1 Speaker
weight 92.5 g (with bracket); Approx. 90 g (without bracket)

BATTERY

BATTERY SPECS
capacity 6741 mAh
cell type Li-ion 4S
charging temperature 5°C to 40°C (41°F to 104°F)
discharge rate 4C
energy 99.5 Wh
low-temperature charging Not supported
max charging power 1.8C
max charging voltage 17.0 V
model DJI Matrice 4E/T Series Intelligent Flight Battery
standard voltage 14.76 V
weight 401 g
