Name: Portable Intelligent Reconnaissance Robot
Brand: Norsat International Inc.
SKU: GTR5218
Price: 20700.00 USD
Availability: InStock

Portable Intelligent Reconnaissance Robot

GTR5218

Portable Intelligent Reconnaissance Robot

GROUND GUARDIAN

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

ADD-ON EXTENDED WARRANTY

Maximum total coverage is 5 years.

View Family Datasheet

[{"id":42813984112823,"title":"iMesh","option1":"iMesh","option2":null,"option3":null,"sku":"GTR5218","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Portable Intelligent Reconnaissance Robot - iMesh","public_title":"iMesh","options":["iMesh"],"price":2070000,"weight":13500,"compare_at_price":0,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":52123208155503,"title":"Point-to-point","option1":"Point-to-point","option2":null,"option3":null,"sku":"GTR5218SE","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Portable Intelligent Reconnaissance Robot - Point-to-point","public_title":"Point-to-point","options":["Point-to-point"],"price":1770000,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

GTR5218(SE) from the Ground Guardian series portable intelligent reconnaissance robot is rugged, small, and lightweight, perfect for carrying in a backpack. The robot survives dropping on the ground and can be quickly deployed in narrow spaces. It moves quietly and fast and is equipped with cameras and pickups to collect real-time audio and video data of the on-site environment, even in darkness.

Individuals can remotely manipulate the robot to certain places or dangerous areas while maintaining a safe distance, monitoring the place or target objects in real time, so as to make decisions and actions quickly.

Standard Accessories

Chassis, Communication Station (w/ antenna & battery); included with GTR5218 only, Controller, Connection Cable, Headset, Charger for Chassis and Charger for Communication Station, Inner Hexagon Tool Set, Transport Case

KEY SPECIFICATIONS
color camera	2, both support infrared night vision
communication protocol	Point-to-multipoint or Wireless Ad Hoc Network (iMesh)
communication station charging time	About 2 hours
communication station working hours	3-5hours (23℃)
dropping height	Up to 4 m
FOV	150°
mobility agility	Zero radius turn
mobility slope	Up to 35°
mobility speed	Up to 7-8 km/h
mobility vertical obstacles	Up to 180 mm
payload	4 kg
runtime	3.5 hours

ELECTRICAL SPECIFICATIONS
battery MTBF	Cycle charge and discharge 500 times (23℃)
camera resolution	1080P
chassis battery	2.5 Ah, 24V
communication distance	1 km
communication frequency	800MHz, 1.4GHz, 2.4GHz, 5.7GHz
communication station battery	6Ah, 12V
communication station power dissipation	4-12W (connecting the Controller)
controller operating system	Android 12
controller power dissipation	3-11W
controller screen	7 inches, 10-point touch
controller storage	RAM 4GB / ROM 32 GB
lightning mode of camera	Infrared Light

INTERFACE SPECIFICATIONS
chassis interface	1 aviation plug
communication station interface	1 aviation plug
controller resolution	1200 * 1920
controller screen luminance	≤1500nit

ENVIRONMENTAL SPECIFICATIONS
IP rating	IP 67
temperature operational	-20°C to +50°C
temperature storage	-25°C to +55°C

PHYSICAL SPECIFICATIONS
chassis height	140 mm
chassis length	298 mm
chassis weight	3.75 kg
chassis width	254.5 mm
communication station height	60.7 mm
communication station length	85 mm
communication station weight	0.7 kg
communication station width	126 mm
controller height	65 mm
controller length	275 mm
controller weight	1.2 kg
controller width	147.5 mm

KEY SPECIFICATIONS
color camera	2, both support infrared night vision
communication protocol	Point-to-multipoint
dropping height	Up to 4 m
FOV	150°
mobility agility	Zero radius turn
mobility slope	Up to 35°
mobility speed	Up to 7-8 km/h
mobility vertical obstacles	Up to 180 mm
payload	4 kg
runtime	3.5 hours

ELECTRICAL SPECIFICATIONS
battery MTBF	Cycle charge and discharge 500 times (23℃)
camera resolution	1080P
chassis battery	2.5 Ah, 24V
communication distance	1 km
communication frequency	800MHz, 1.4GHz, 2.4GHz, 5.7GHz
controller battery	10200 mAh, 7.4V
controller charging	USB-C (Type-C)
controller charging time	5 hours
controller external device	USB-A
controller external storage	TF Card Slot / USB-A
controller file transfer	USB-A / USB-C
controller mobile network	SIM card slot
controller operating system	Android 9.0
controller run time	13 hours
controller screen	5.5-inch 1080P HD High-brightness LCD Touch Display Screen
controller storage	RAM 2 G, 16G Storage
lightning mode of camera	Infrared Light

INTERFACE SPECIFICATIONS
chassis interface	1 aviation plug

ENVIRONMENTAL SPECIFICATIONS
controller communication range	1 km
controller IP rating	IP 53
controller temperature operational	-10°C to +50°C
IP rating	IP 67
temperature operational	-20°C to +50°C
temperature storage	-25°C to +55°C

PHYSICAL SPECIFICATIONS
chassis height	140 mm
chassis length	298 mm
chassis weight	3.75 kg
chassis width	254.5 mm
controller height	41 mm
controller length	189 mm
controller weight	0.85 kg
controller width	138 mm

Please contact us to request any additional documents you may need.

INFORMATION
HS Code	8479899990
Country of Origin	Made in China
Ex Works	Richmond, BC, Canada
ECCN Number	EAR99
Warranty	1 year
Unit Package Dimensions	670 x 350 x 289 mm
Unit Package Weight	13.5 kg
Total Aluminium Content	0 kg
Aluminum Country of Smelt and Cast	-
Total Aluminium Value	$
