| KEY SPECIFICATIONS | |
|---|---|
| color camera | 2, both support infrared night vision |
| communication protocol | Point-to-multipoint |
| dropping height | Up to 3 m |
| FOV | 150° |
| mobility agility | Zero radius turn |
| mobility slope | Up to 35° |
| mobility speed | 7.2 km/h |
| mobility vertical obstacles | Up to 170 mm |
| payload | 5 kg |
| runtime | 2.5 hours |
| ELECTRICAL SPECIFICATIONS | |
|---|---|
| battery MTBF | Cycle charge and discharge 500 times (23℃) |
| camera resolution | 1080P |
| chassis battery | 2.4Ah,24V |
| communication distance | 1 km |
| communication frequency | 800MHz, 1.4GHz, 2.4GHz, 5.7GHz |
| controller battery | 10200 mAh, 7.4V |
| controller charging | USB-C (Type-C) |
| controller charging time | 5 hours |
| controller external device | USB-A |
| controller external storage | TF Card Slot / USB-A |
| controller file transfer | USB-A / USB-C |
| controller mobile network | SIM card slot |
| controller operating system | Android 9.0 |
| controller run time | 13 hours |
| controller screen | 5.5-inch 1080P HD High-brightness LCD Touch Display Screen |
| controller storage | RAM 2 G, 16G Storage |
| lightning mode of camera | Infrared Light |
| INTERFACE SPECIFICATIONS | |
|---|---|
| chassis interface | 1 aviation plug |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| controller communication range | 1 km |
| controller IP rating | IP 53 |
| controller temperature operational | -10°C to +50°C |
| IP rating | IP 67 |
| temperature operational | -20°C to +50°C |
| temperature storage | -25°C to +55°C |
| PHYSICAL SPECIFICATIONS | |
|---|---|
| chassis height | 155 mm |
| chassis length | 337.3 mm |
| chassis weight | 4.5 kg |
| chassis width | 300 mm |
| controller height | 41 mm |
| controller length | 189 mm |
| controller weight | 0.85 kg |
| controller width | 138 mm |
