GTR0212

Portable Tracked All-terrain Robot

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

Only 0 items in stock!
Maximum total coverage is 5 years.



KEY SPECIFICATIONS
color camera 3, both support infrared night vision
communication protocol Point-to-multipoint
communication station charging time 5 hours
communication station working hours 13 hours
FOV 150°
maximum load 15 kg
maximum slope 25°
maximum speed 10km/h
mobility agility Highly Agile
mobility slope Up to 35°
mobility speed 9.5 km/h
mobility vertical obstacles Up to 150 mm
non-load runtime 3h
normal walking speed 10km/h
payload 15 kg
runtime 3.5 hours
Product Revision A
ELECTRICAL SPECIFICATIONS
autonomous charging No
battery Lithium-ion
battery capacity 5Ah x 2, 30V
camera resolution 1080P
communication distance 1 km
communication frequency 800MHz, 1.4GHz, 2.4GHz, 5.7GHz
controller operating system Android 9.0
controller screen 5.5 inches, LCD screen
controller storage RAM 2GB / ROM 16 GB
lightning mode of camera 2 Infrared and White Light
nominal battery voltage 48V
INTERFACE SPECIFICATIONS
chassis interface 2 aviation plug
controller resolution 1920 * 1080
ENVIRONMENTAL SPECIFICATIONS
IP rating IP 54
temperature operational -20°C to +50°C
temperature storage -25°C - +55°C
PHYSICAL SPECIFICATIONS
chassis height 257 mm
chassis length 753 mm
chassis weight 20KG
chassis width 558 mm
controller height 41 mm
controller length 189 mm
controller weight 0.85 kg
controller width 138 mm
load bearing 15 kg
product height 257 mm
product length 753 mm
product weight 20 kg
product width 558 mm
