Name: SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m
Brand: Norsat International Inc.
SKU: STD30020A
Price: 463334.00 USD
Availability: InStock

SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m

STD30020A

SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m

SKYLARK Series

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

ADD-ON EXTENDED WARRANTY

Maximum total coverage is 5 years.

[{"id":51992379949423,"title":"12V","option1":"12V","option2":null,"option3":null,"sku":"STD30020A","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m - 12V","public_title":"12V","options":["12V"],"price":46333400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":51992379982191,"title":"24V","option1":"24V","option2":null,"option3":null,"sku":"STD30020B","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m - 24V","public_title":"24V","options":["24V"],"price":46333400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":51992380014959,"title":"48V","option1":"48V","option2":null,"option3":null,"sku":"STD30020C","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SKYLARK Industry-specific Tethered UAV - Max Ceiling 300m - 48V","public_title":"48V","options":["48V"],"price":46333400,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

STD300 Series is an industry-specific tethered UAV with a net load of 15kg@300m and 20Kg@ 200m. Supplied by ground electric through tethered cable, it is hover in the air for 24 hours. The tethered UAV with base station equipment can be used for emergency communication during disasters like flood, earthquake, typhoon, etc. It can also carry Optical Zoom Lens Camera, Electrical Optical Pod, Communication Relay Station, Ad-Hoc Equipment, IR, High Intensity Light, Loudspeaker for different scenarios.

KEY SPECIFICATIONS
ascending speed	4 m/s
cable length	312m
ceiling	300 m
descending speed	2 m/s
hovering accuracy horizontal	±10cm (RTK)
hovering accuracy vertical	±10cm (RTK)
maximum payload	15 kg @ 300m; 20 kg @ 200m
maximum taking-off weight	40 kg
optical fiber	Single-mode
payload	Depends on the device to be mounted
signal transmission	Wireless or Wire
support antenna	Omnidirectional Antenna
UAV Type	Hexa-copter Tether UAV
WIFI transmission frequency	2.4 GHz
Product Revision	A

ELECTRICAL SPECIFICATIONS
power	Industrial power or generator
power mode	50 Hz
voltage	AC 380V 10kw
voltage for payload	12V

ENVIRONMENTAL SPECIFICATIONS
security	Automatic landing when ground power supply is interrupted; Automatic landing when the control signal is interrupted
temperature operational	-25°C to +55°C
temperature storage	-25℃ to 55℃
wind resistance	Level 6

PHYSICAL SPECIFICATIONS
control method	Manual/automatic control by remote control; Automatic control from ground station
fold product height	810 mm
fold product length	610 mm
fold product width	480 mm
function	Automatic cable retracting and releasing, intelligent automatic cable arrangement
mission payload	Communication base station equipment,gimbal and EO & IR cameras, lighting/loudspeaker systems
product weight	26 kg
releasing cable	Automatic
retracting cable	Automatic
roter size	30''
symmetric motor wheelbase	1630 mm
unfold product height	825 mm
unfold product length	2392 mm
unfold product width	1525 mm

KEY SPECIFICATIONS
ascending speed	4 m/s
cable length	312m
ceiling	300 m
descending speed	2 m/s
hovering accuracy horizontal	±10cm (RTK)
hovering accuracy vertical	±10cm (RTK)
maximum payload	15 kg @ 300m; 20 kg @ 200m
maximum taking-off weight	40 kg
optical fiber	Single-mode
payload	Depends on the device to be mounted
signal transmission	Wireless or Wire
support antenna	Omnidirectional Antenna
UAV Type	Hexa-copter Tether UAV
WIFI transmission frequency	2.4 GHz
Product Revision	A

ELECTRICAL SPECIFICATIONS
power	Industrial power or generator
power mode	50 Hz
voltage	AC 380V 10kw
voltage for payload	24V

ENVIRONMENTAL SPECIFICATIONS
security	Automatic landing when ground power supply is interrupted; Automatic landing when the control signal is interrupted
temperature operational	-25°C to +55°C
temperature storage	-25℃ to 55℃
wind resistance	Level 6

PHYSICAL SPECIFICATIONS
control method	Manual/automatic control by remote control; Automatic control from ground station
fold product height	810 mm
fold product length	610 mm
fold product width	480 mm
function	Automatic cable retracting and releasing, intelligent automatic cable arrangement
mission payload	Communication base station equipment,gimbal and EO & IR cameras, lighting/loudspeaker systems
product weight	26 kg
releasing cable	Automatic
retracting cable	Automatic
roter size	30''
symmetric motor wheelbase	1630 mm
unfold product height	825 mm
unfold product length	2392 mm
unfold product width	1525 mm

KEY SPECIFICATIONS
ascending speed	4 m/s
cable length	312m
ceiling	300 m
descending speed	2 m/s
hovering accuracy horizontal	±10cm (RTK)
hovering accuracy vertical	±10cm (RTK)
maximum payload	15 kg @ 300m; 20 kg @ 200m
maximum taking-off weight	40 kg
optical fiber	Single-mode
payload	Depends on the device to be mounted
signal transmission	Wireless or Wire
support antenna	Omnidirectional Antenna
UAV Type	Hexa-copter Tether UAV
WIFI transmission frequency	2.4 GHz
Product Revision	A

ELECTRICAL SPECIFICATIONS
power	Industrial power or generator
power mode	50 Hz
voltage	AC 380V 10kw
voltage for payload	48V

ENVIRONMENTAL SPECIFICATIONS
security	Automatic landing when ground power supply is interrupted; Automatic landing when the control signal is interrupted
temperature operational	-25°C to +55°C
temperature storage	-25℃ to 55℃
wind resistance	Level 6

PHYSICAL SPECIFICATIONS
control method	Manual/automatic control by remote control; Automatic control from ground station
fold product height	810 mm
fold product length	610 mm
fold product width	480 mm
function	Automatic cable retracting and releasing, intelligent automatic cable arrangement
mission payload	Communication base station equipment,gimbal and EO & IR cameras, lighting/loudspeaker systems
product weight	26 kg
releasing cable	Automatic
retracting cable	Automatic
roter size	30''
symmetric motor wheelbase	1630 mm
unfold product height	825 mm
unfold product length	2392 mm
unfold product width	1525 mm

Please contact us to request any additional documents you may need.

INFORMATION
HS Code	8806939090
Country of Origin	Made in China
Ex Works	Richmond, BC, Canada
ECCN Number	-
Warranty	1 year
Unit Package Dimensions	670 x 540 x 1060 mm
Unit Package Weight	121 kg
Total Aluminium Content	-
Aluminum Country of Smelt and Cast	-
Total Aluminium Value	-
