Name: Single-Band C-Band BDC (25 kHz max.)
Brand: Norsat International Inc.
SKU: BDC-C25HACF
Price: 1556.00 USD
Availability: InStock

BDC-C25HACF

Single-Band C-Band BDC (25 kHz max.)

BDC Series

Please sign in or create an account to view the price and availability.

(Scroll to see specifications and documents)

[{"id":42776125079735,"title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ F Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Output connector only","option3":"F Connector","sku":"BDC-C25HACF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Output connector only \/ F Connector","public_title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ F Connector","options":["A: 3.4 - 4.2 GHz","Output connector only","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125112503,"title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ N Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Output connector only","option3":"N Connector","sku":"BDC-C25HACN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Output connector only \/ N Connector","public_title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ N Connector","options":["A: 3.4 - 4.2 GHz","Output connector only","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125145271,"title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ SMA Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Output connector only","option3":"SMA Connector","sku":"BDC-C25HACS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Output connector only \/ SMA Connector","public_title":"A: 3.4 - 4.2 GHz \/ Output connector only \/ SMA Connector","options":["A: 3.4 - 4.2 GHz","Output connector only","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125178039,"title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ F Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed \u0026 output connector","option3":"F Connector","sku":"BDC-C25HADF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ F Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ F Connector","options":["A: 3.4 - 4.2 GHz","Feed \u0026 output connector","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125210807,"title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ N Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed \u0026 output connector","option3":"N Connector","sku":"BDC-C25HADN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ N Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ N Connector","options":["A: 3.4 - 4.2 GHz","Feed \u0026 output connector","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125243575,"title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ SMA Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed \u0026 output connector","option3":"SMA Connector","sku":"BDC-C25HADS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ SMA Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed \u0026 output connector \/ SMA Connector","options":["A: 3.4 - 4.2 GHz","Feed \u0026 output connector","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125276343,"title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ F Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed through con. only","option3":"F Connector","sku":"BDC-C25HAPF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed through con. only \/ F Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ F Connector","options":["A: 3.4 - 4.2 GHz","Feed through con. only","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125309111,"title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ N Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed through con. only","option3":"N Connector","sku":"BDC-C25HAPN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed through con. only \/ N Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ N Connector","options":["A: 3.4 - 4.2 GHz","Feed through con. only","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125341879,"title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ SMA Connector","option1":"A: 3.4 - 4.2 GHz","option2":"Feed through con. only","option3":"SMA Connector","sku":"BDC-C25HAPS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - A: 3.4 - 4.2 GHz \/ Feed through con. only \/ SMA Connector","public_title":"A: 3.4 - 4.2 GHz \/ Feed through con. only \/ SMA Connector","options":["A: 3.4 - 4.2 GHz","Feed through con. only","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125374647,"title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ F Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Output connector only","option3":"F Connector","sku":"BDC-C25HBCF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Output connector only \/ F Connector","public_title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ F Connector","options":["B: 4.5 - 4.8 GHz","Output connector only","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125407415,"title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ N Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Output connector only","option3":"N Connector","sku":"BDC-C25HBCN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Output connector only \/ N Connector","public_title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ N Connector","options":["B: 4.5 - 4.8 GHz","Output connector only","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125440183,"title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ SMA Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Output connector only","option3":"SMA Connector","sku":"BDC-C25HBCS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Output connector only \/ SMA Connector","public_title":"B: 4.5 - 4.8 GHz \/ Output connector only \/ SMA Connector","options":["B: 4.5 - 4.8 GHz","Output connector only","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125472951,"title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ F Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed \u0026 output connector","option3":"F Connector","sku":"BDC-C25HBDF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ F Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ F Connector","options":["B: 4.5 - 4.8 GHz","Feed \u0026 output connector","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125505719,"title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ N Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed \u0026 output connector","option3":"N Connector","sku":"BDC-C25HBDN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ N Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ N Connector","options":["B: 4.5 - 4.8 GHz","Feed \u0026 output connector","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125538487,"title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ SMA Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed \u0026 output connector","option3":"SMA Connector","sku":"BDC-C25HBDS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ SMA Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed \u0026 output connector \/ SMA Connector","options":["B: 4.5 - 4.8 GHz","Feed \u0026 output connector","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125571255,"title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ F Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed through con. only","option3":"F Connector","sku":"BDC-C25HBPF","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed through con. only \/ F Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ F Connector","options":["B: 4.5 - 4.8 GHz","Feed through con. only","F Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125604023,"title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ N Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed through con. only","option3":"N Connector","sku":"BDC-C25HBPN","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed through con. only \/ N Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ N Connector","options":["B: 4.5 - 4.8 GHz","Feed through con. only","N Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42776125636791,"title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ SMA Connector","option1":"B: 4.5 - 4.8 GHz","option2":"Feed through con. only","option3":"SMA Connector","sku":"BDC-C25HBPS","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Single-Band C-Band BDC (25 kHz max.) - B: 4.5 - 4.8 GHz \/ Feed through con. only \/ SMA Connector","public_title":"B: 4.5 - 4.8 GHz \/ Feed through con. only \/ SMA Connector","options":["B: 4.5 - 4.8 GHz","Feed through con. only","SMA Connector"],"price":155600,"weight":620,"compare_at_price":140000,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

KEY SPECIFICATIONS
band	C-Band
input frequency band 1	3.40 - 4.20 GHz
LO frequency 1	5.15 GHz
LO stability	25 kHz max.
noise figure	10 dB max.
output frequency band 1	950 - 1750 MHz
reference type	Internal Reference
Product Revision	A

RF SPECIFICATIONS
conversion gain max	43 dB
conversion gain min	37 dB
conversion gain typ	40 dB
gain flatness	4 dB p-p max.
gain ripple (at per 36MHz)	1 dB p-p max.
image rejection	45 dBc min.
input VSWR	2.0 : 1 max.
output P1dB	5 dB max.
output VSWR	2.0 : 1 max.

ELECTRICAL SPECIFICATIONS
current consumption	300 mA max.
input power	Output connector only
power requirements	+12 to +24 V DC

INTERFACE SPECIFICATIONS
RF input connector	SMA Connector
RF output connector	F Connector

ENVIRONMENTAL SPECIFICATIONS
IP rating	IP 67
temperature operational	-40°C to +60°C

PHYSICAL SPECIFICATIONS
product height	46.0 mm
product length	108 mm
product weight	0.62 kg
product width	94 mm

Back to New Products

KEY SPECIFICATIONS
band	C-Band
external ref freq	10 MHz, -5 to +5 dBm
input frequency band 1	4.50 - 4.80 GHz
LO frequency 1	5.95 GHz
LO stability	25 kHz max.
noise figure	10 dB max.
output frequency band 1	1150 - 1450 MHz
reference type	Internal Reference
Product Revision	A

INFORMATION
HS Code	8517690000
Country of Origin	Made in the Republic of Korea
Ex Works	Richmond, BC, Canada
ECCN Number	EAR99
Warranty	3 years
Unit Package Dimensions	190 mm x 115 mm x 75 mm
Unit Package Weight	0.62 kg
Aluminium Content	0.46 Kg
Aluminium COO	Made in the Republic of Korea
Aluminium Total Value	$ 1.15
